Catnic Cougar Cavity Wall Lintel 900mm Black
SKU: LNCNE151
IDLNCNE151
Building Materials > Lintels > Metal Lintels > Catnic Cougar Cavity Wall Lintel 900mm Black
https://www.jewson.co.uk/p/catnic-cougar-cavity-wall-lintel-900mm-black-LNCNE151
£58
.81
inc VAT
each
49.01
http://schema.org/InStock
£65.34
per metre
Please Sign in/register to save items.
Product information
The Catnic Cougar Cavity Wall Lintel is designed to accommodate the requirements of all thin joint wall constructions. It measures 900 x 283mm (L x W) . The product is manufactured from galvanised steel, then powder coated for weather and abrasion resistance. The lintel is provided with integral plaster key with staggered slots applied to the inner flange and underside of insulation. The product supports the uniform distribution of masonry loads, timber floors and roof loads.
Features & benefits
- Duplex Corrosion Protection System: Manufactured from hot-dipped Galvanised steel to BS EN 10346:2009 plus coating tupe Z275. A coating of thermal setting polyester powder is then applied by electrostatic process, further protecting the lintel.
- Integrated Plaster Key that avoid the hazards of working with a mesh key
- Supplied with CFC and HCFC free insulation maximising their thermal efficiency and compliance with part L
- BSI registered with quality management systems in accordance with BS EN ISO 9001: 2015
Specifications
Product Name | Catnic Cougar Cavity Wall Lintel 900mm Black |
Brand | Catnic |
Manufacturer Name | Tata Steel |
Manufacturer Part Number | CG90/1000900 |
EAN | 5017586519159 |
Compliance Approvals | BBA Certified |
Warranty Period | 60 years |
Materials | Galvanised Steel |
Commercial Or Domestic Use | Both |
Range | Cavity Wall |
Colour | Black |
Application | External |
Pack Quantity | 1 |
Country Of Origin | United Kingdom |
Finish | Galvanised Powder Coated |
Recyclable | Yes |
Product Width | 283 mm |
Product Weight | 6.1 kg/m |
Product Height | 140 mm |
Product Length | 900 mm |
Thickness | 2.5 mm |
Moisture Resistant | Yes |
Thermal Conductivity | 50 W/m2K |
Cavity Width | 105 mm |
