Catnic Cougar Open Back Cavity Wall Lintel 2400 x 283mm Black

SKU: LNCNE161
IDLNCNE161 Building Materials > Lintels > Metal Lintels > Catnic Cougar Open Back Cavity Wall Lintel 2400 x 283mm Black
Trade Sign in or apply for trade prices
£169
.19
 inc VAT
 each
140.99 http://schema.org/InStock
£70.50 per metre


Qty Quantity

Click & Collect

Collect in 1 hour

Click & Deliver

Next day if ordered by 12pm


Please log in/register  to save items.

Product information

The Catnic Cougar Open Back Cavity Wall Lintel Black is used in construction of 90-105mm cavity walls. It measures 2400 x 283mm (L x W). The product is made from galvanised steel and has a powder-coated finish. It is used to support masonry loads, timber floors and roof loads by uniform distribution of up to 22kN of weight. This lintel is also suitable for 100-115mm inner leaf masonry. The built-in plaster key ensures effective bonding to smooth surfaces. The use of galvanised steel provides duplex corrosion and rust protection that ensures longevity in external applications. Insulation is also incorporated into the lintel's design which helps in adjusting to temperature fluctuations efficiently. Catnic is the leading UK manufacturer of steel lintels.

Features & benefits
  • Duplex Corrosion Protection System: Manufactured from hot-dipped Galvanised steel to BS EN 10346:2009 plus coating tupe Z275. A coating of thermal setting polyester powder is then applied by electrostatic process, further protecting the lintel.
  • Integrated Plaster Key that avoid the hazards of working with a mesh key
  • Supplied with CFC and HCFC free insulation maximising their thermal efficiency and compliance with part L
  • BSI registered with quality management systems in accordance with BS EN ISO 9001: 2015

Specifications
Product Name Catnic Cougar Open Back Cavity Wall Lintel 2400 x 283mm Black
Brand Catnic
Manufacturer Name Tata Steel
Manufacturer Part Number CG90/1002400
EAN 5017586519203
Compliance Approvals BBA Certified
Warranty Period 60  months
Materials Galvanised Steel
Commercial Or Domestic Use Both
Range Cavity Wall Lintel
Model Number Galvanised Powder Coated
Colour Black
Application External
Pack Quantity 1
Country Of Origin United Kingdom
Recyclable Yes
Product Width 283  mm
Product Weight 8.9  kg/m
Product Height 180  mm
Product Length 2400  mm
Thickness 2.5  mm
Moisture Resistant Yes
Cavity Width 105  mm
