Catnic Cougar Open Back Cavity Wall Lintel 2700 x 283mm BlackSKU: LNCNE163
The Catnic Cougar Open Back Cavity Wall Lintel Black is used in the construction of 90-105mm cavity walls. It measures 2700 x 283mm (L x W). The product is made from galvanised steel and has a powder-coated finish. It is used to support masonry loads, timber floors and roof loads by uniform distribution of up to 26kN of weight. This lintel is also suitable for 100-115mm inner leaf masonry. The built-in plaster key ensures effective bonding to smooth surfaces. The use of galvanised steel provides duplex corrosion and rust protection that ensures longevity in external applications. Insulation is also incorporated into the lintel's design which helps in adjusting to temperature fluctuations efficiently.
- Duplex Corrosion Protection System: Manufactured from hot-dipped Galvanised steel to BS EN 10346:2009 plus coating tupe Z275. A coating of thermal setting polyester powder is then applied by electrostatic process, further protecting the lintel.
- Integrated Plaster Key that avoid the hazards of working with a mesh key
- Supplied with CFC and HCFC free insulation maximising their thermal efficiency and compliance with part L
- BSI registered with quality management systems in accordance with BS EN ISO 9001: 2015
|Product Name||Catnic Cougar Open Back Cavity Wall Lintel 2700 x 283mm Black|
|Manufacturer Name||Tata Steel|
|Manufacturer Part Number||CG90/1002700|
|Compliance Approvals||BBA Certified|
|Warranty Period||60 years|
|Commercial Or Domestic Use||Both|
|Range||Cavity Wall Lintel|
|Country Of Origin||United Kingdom|
|Finish||Galvanised Powder Coated|
|Product Width||283 mm|
|Product Weight||10.2 kg/m|
|Product Height||220 mm|
|Product Length||2700 mm|
|Cavity Width||105 mm|
