Timloc InvisiWeep Vent 102 x 65 x 10mm Buff
SKU: TLIW50BU
Timloc InvisiWeep Vent 102 x 65 x 10mm (L x H x W) Buff Pack of 50 is a multi-function system that discharges water from external walls. The vent is injection moulded from polypropylene material. It is used with Timloc cavity tray system, over external lintels and also at ground floor level. This Timloc vent satisfies all NHBC requirements and complies with British standards of BS5250.
Features & benefits
- Low profile water outlet - Ensuring minimal visibility when fitted, the water outlet in unobtrusive to the naked eye.
- Venturi effect outlet tube - Reduces pressure, allowing for optimal water drainage.
- Full height upstand to cavity side - Enables drainage, reducing the risk of blockage if cement builds up in the cavity.
- External ribs and tapered profile - To key mortar for a secure fixing.
- 4mm vermin barrier and baffle - Keeps out nest building insects and reduces rainwater penetration to the cavity.
IDTLIW50BU
Building Materials > Bricks & Blocks > Damp Proof Membranes > Timloc InvisiWeep Vent 102 x 65 x 10mm Buff
https://www.jewson.co.uk/p/timloc-invisiweep-vent-102-x-65-x-10mm-buff-TLIW50BU
Timloc InvisiWeep Vent 102 x 65 x 10mm (L x H x W) Buff Pack of 50 is a multi-function system that discharges water from external walls. The vent is injection moulded from polypropylene material. It is used with Timloc cavity tray system, over external lintels and also at ground floor level. This Timloc vent satisfies all NHBC requirements and complies with British standards of BS5250.
Features & benefits
- Low profile water outlet - Ensuring minimal visibility when fitted, the water outlet in unobtrusive to the naked eye.
- Venturi effect outlet tube - Reduces pressure, allowing for optimal water drainage.
- Full height upstand to cavity side - Enables drainage, reducing the risk of blockage if cement builds up in the cavity.
- External ribs and tapered profile - To key mortar for a secure fixing.
- 4mm vermin barrier and baffle - Keeps out nest building insects and reduces rainwater penetration to the cavity.
Specifications
| Product Name | Timloc InvisiWeep Vent 102 x 65 x 10mm Buff |
| Brand | Timloc |
| Manufacturer Name | Timloc |
| Manufacturer Part Number | IW50BU |
| Materials | Polypropylene |
| Range | Weep Vent |
| Colour | Buff |
| Application | Interior/External |
| Pack Quantity | 1 |
| Country Of Origin | United Kingdom |
| Product Width | 10 mm |
| Product Height | 65 mm |
| Product Length | 102 mm |
