Union 2200 BS StrongBOLT 5 Lever Sashlock 68mm Chrome
SKU: Y22SSC25
The UNION StrongBOLT 2200 BS 5 Lever Sashlock is a high-security modular lock suitable for timber doors up to 54mm thick. It features anti-pick, anti-saw and anti-drill security, a 20mm chamfered deadbolt for added protection, and hardened steel pins for resistance to sawing. The lock is kitemarked to BS3621: 2007 and approved by the police Secured by Design initiative, making it recommended by insurance companies. The radius inner forend allows for easy installation without additional carpentry, and the lock comes with a 10-year guarantee. It's suitable for use with Euro profile cylinders and is lockable from either side.
Features & benefits
- Supplied with 2 steel nickel plated keys, instructions & fixings
- Follower 8mm square
- Latch Bolt Reversible
- 20mm deadbolt throw
- Anti pick, anti drill and anti saw security for resistance against attack
- Suitable for doors up to 54mm thick
- Can be used on left or right handed doors
- Suitable for use on 30 & 60 minute fire doors
- CE marked & tested to BS3621:2007
- EN122209 approved
IDY22SSC25
Doors & Joinery > Ironmongery > Door Locks & Security > Union 2200 BS StrongBOLT 5 Lever Sashlock 68mm Chrome
https://www.jewson.co.uk/p/union-strongbolt-2200-bs-5-lever-sashlock-68mm-d-chrome-Y22SSC25
The UNION StrongBOLT 2200 BS 5 Lever Sashlock is a high-security modular lock suitable for timber doors up to 54mm thick. It features anti-pick, anti-saw and anti-drill security, a 20mm chamfered deadbolt for added protection, and hardened steel pins for resistance to sawing. The lock is kitemarked to BS3621: 2007 and approved by the police Secured by Design initiative, making it recommended by insurance companies. The radius inner forend allows for easy installation without additional carpentry, and the lock comes with a 10-year guarantee. It's suitable for use with Euro profile cylinders and is lockable from either side.
Features & benefits
- Supplied with 2 steel nickel plated keys, instructions & fixings
- Follower 8mm square
- Latch Bolt Reversible
- 20mm deadbolt throw
- Anti pick, anti drill and anti saw security for resistance against attack
- Suitable for doors up to 54mm thick
- Can be used on left or right handed doors
- Suitable for use on 30 & 60 minute fire doors
- CE marked & tested to BS3621:2007
- EN122209 approved
Specifications
| Product Name | Union 2200 BS StrongBOLT 5 Lever Sashlock 68mm Chrome |
| Brand | Union |
| Product Type | Sashlock |
| Manufacturer Name | Assa Abloy Ltd |
| Manufacturer Part Number | Y2200S-SC-2.5 |
| EAN | 5011802165465 |
| Compliance Approvals | CE Marked |
| Warranty Period | 10 years |
| Materials |
Zinc
Steel |
| Range | 5 Lever |
| Pack Quantity | 1 |
| Country Of Origin | United Kingdom |
| Applicable Standards | bs 3621 2007,certifire,en 12209,en 1634 1,secured by design,ukca |
| Finish | Satin Chrome |
| Product Depth | 68 mm |
| Case Size | 63.5 mm |
| Bolt Throw | 20 mm |
| Backset | 45 mm |
